SU-DD2 STONE is the downdraft hood which perfectly blends in with every kind of kitchen worktop.
You can customise the upper panel with the same worktop finish. Together with Sirius “frameless” installation technology, when the hood is off, you get a unique flush top effect. Then, when in function, the downdraft rises from the worktop.
This product is available in 24", 36" and 48", the structure is in Aisi 304 stainless steel and it is equipped with a high efficiency and dynamic Led lighting.
You can choose between different kind of installations, that is with on board motor or remote motors (indoor or outdoor)

SU-DD2 STONE

Motor:
motor on board or external motor (not included, to be purchased separately)
Lighting:
1x3.75 W Dimmable and dynamic Led bar for 24”version (2700 to 6500°K)
1x6 W Dimmable and dynamic Led bar for 36” version (2700 to 6500°K)
2x3.75 W Dimmable and dynamic Led bar for 48” version (2700 to 6500°K)
Control Panel:
Touch control 4 speeds+delay off timer+light switch
Remote control
Grease filter:
anodized aluminium (5 layers)
Air Outlet:
6" round (front and back) or rectangular 9"11/16x3"5/32 (sides and below)

Accessories:
Charcoal filter:
KF10 (order 2 pcs for 24" version) cod. 60071010999
KF9 (order 2 pcs for 36" version) cod. 60071009999
KF12 (order 2 pcs for 48" version) cod. 60070069069

Cut Out:
Create a niche in the countertop using the following dimensions
3”15/16 x 21”5/32 R10 ( 24” version)
3”15/16 x 32”15/16 R10 (36” version)
3”15/16 x 44”3/4 R10 (48” version)

Anti-crushing safety system

Technologies

The hood SU-DD2 STONE is equipped with the following technologies

Request information

ENERGY LABEL

PRODUCT DIM. MOTOR
SU-DD2 STONE external motor version SUM1 Drawing
SU-DD2 STONE external motor version SUM6 Drawing
SU-DD2 STONE motor on board version Motor on board SU-DD Drawing
